Cut to Length Line

      The steel cut to length machine, is used for uncoiling, leveling, transversely cutting different kinds of steel coils into fixed length plates and then piled up neatly.

      Process: Uncoiling - Leveling - Shearing - Stacking
      Applicable Material: Cold Rolled Plate, Electric Galvanizing Plate, Hot Dip Galvanized Plate, Color Coating Plate, Stainless Steel Plate, Aluminium Plate, Copper Plate, etc.
      Material Thickness: 0.5 - 4.0mm Material Width: 300 - 1800mm
      Finished Products Length: 300 - 6,000mm Length Accuracy: +0.3mm
      Diagnoal Accuracy: +0.5mm Leveling Accuracy: 1mnh/m
      Max. Speed: 70 - 90m/min (Max.160m/min For Thin Tinplate & Aluminium Plate)

Typical Achievements:
